Blower Performance Data – TC030
Rated
CFM
Min CFM
Motor
Type
Motor Speed
Setting
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
1000 750 PSC
Low CFM 1017 979 931 884 827 751
Medium CFM 1140 1093 1036 988 922 846
High CFM 1102 1045 979 903 798
1000 750
PSC -
High
Static
Low CFM 979 941 912 865 798
Medium CFM 1074 979 884 779
High CFM 1102 988 874 760
1000 750
ECM -
Constant
Torque
1
RPM 880 925 994 1049 1101
Power (W) 158 165 176 184 192
CFM 904 873 832 796 763
2
RPM 956 998 1038 1105 1156 1203 1248 1295 1344
Power (W) 211 219 227 240 250 258 267 276 285
CFM 1020 992 965 927 894 864 835 805 771
3
RPM 1034 1072 1110 1145 1209 1250 1303 1346 1387 1422
Power (W) 280 289 298 306 321 330 342 351 361 368
CFM 1139 1113 1089 1064 1027 999 966 937 910 879
4
RPM 1095 1130 1166 1201 1237 1299 1337 1387 1428 1465
Power (W) 336 346 355 364 374 389 399 413 423 430
CFM 1216 1193 1168 1146 1123 1086 1062 1028 1002 975
5
RPM 1268 1301 1333 1394 1426 1473 1491
Power (W) 452 462 471 490 499 508 478
CFM 1250 1229 1208 1173 1151 1112 1036
1000 750
ECM -
Constant
Volume
Minimum CFM
RPM 872 928 990 1046 1096 1143 1192 1238 1282 1327
Power (W) 71 89 108 127 145 162 181 199 217 235
CFM 750 750 750 750 750 750 750 750 750 750
Default CFM
RPM 1131 1177 1218 1252 1295 1337 1381 1415
Power (W) 251 274 296 315 337 362 387 407
CFM 1000 1000 1000 1000 1000 1000 1000 1000
Maximum CFM
RPM 1260 1299 1334 1373 1403
Power (W) 388 410 431 453 471
CFM 1150 1150 1150 1150 1150
See ECM control section for details on setting airow.
Airow is controlled within 5% up to the Max ESP shown with wet coil.
Do not select Dehumidication mode if HP CFM is on setting 1.
ClimaDry is factory wired to operate in stage 2 airow.
Black areas denote ESP where operation is not recommended.
PSC: Units factory shipped on medium speed. Other speeds require eld selection.
CT ECM: Units factory shipped on Speed Tap 2 for Fan-Only and Speed Tap 3 for Heating/Cooling.
All airow is rated and shown above at the lower voltage if unit is dual voltage rated, e.g. 208V for 208-230V units.
Only two speed PSC fan (H & M) available on 575V units.
Performance stated is at the rated power supply. Performance may vary as the power supply varies from the rated.
All data is shown wet coil with clean 1” lter.
All data is ran at 80 °F DB and 67 °F WB.
CFM Tolerance is 7%.
RPM/Watt Tolerance 10%.
