Blower Performance Data – TC060
Rated
CFM
Min CFM
Motor
Type
Motor Speed
Setting
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
1950 1500 PSC
Low CFM 1803 1774 1744 1695 1637 1568
Medium CFM 1999 1950 1901 1852 1793 1744 1676 1588
High CFM 1881 1815 1710 1596 1416 1216 1216
1950 1500
PSC -
High
Static
Low CFM 1882 1872 1852 1842 1813 1793 1764 1715 1666 1588
Medium CFM 2107 2097 2038 1999 1980 1940 1891 1842 1460 1715
High CFM 2342 2323 2293 2254 2195 2156 2087 2019 1940 1852
1950 1500
ECM -
Constant
Torque
1
RPM 768 797 830 863
Power (W) 342 354 366 380
CFM 1685 1640 1593 1545
2
RPM 836 867 895 922 955 989 1020 1048 1081
Power (W) 460 476 489 501 518 533 548 561 577
CFM 1879 1833 1795 1754 1705 1657 1608 1563 1514
3
RPM 923 953 974 1000 1025 1052 1079 1109 1137
Power (W) 648 666 678 694 708 724 740 757 773
CFM 2113 2069 2039 1998 1963 1925 1885 1840 1795
4
RPM 972 994 1020 1041 1066 1090 1114 1144 1170
Power (W) 771 785 803 817 832 848 864 883 900
CFM 2235 2198 2163 2130 2094 2061 2019 1977 1939
5
RPM 1003 1025 1050 1074 1099 1122 1147 1166 1194 1209
Power (W) 866 881 899 916 934 951 970 977 973 969
CFM 2322 2290 2253 2219 2188 2152 2120 2083 2013 1940
1950 1500
ECM -
Constant
Volume
Minimum CFM
RPM 705 773 836 894 949 998 1044 1085 1121 1153
Power (W) 246 301 354 405 453 500 544 587 627 665
CFM 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500
Default CFM
RPM 852 899 949 992 1031 1085 1136 1179 1225 1272
Power (W) 501 562 629 683 731 804 871 926 986 1047
CFM 1950 1950 1950 1950 1950 1950 1950 1950 1950 1950
Maximum CFM
RPM 995 1020 1044 1069 1094
Power (W) 885 896 901 916 937
CFM 2200 2200 2200 2200 2200
See ECM control section for details on setting airow.
Airow is controlled within 5% up to the Max ESP shown with wet coil.
Do not select Dehumidication mode if HP CFM is on setting 1.
ClimaDry is factory wired to operate in stage 2 airow.
Black areas denote ESP where operation is not recommended.
PSC: Units factory shipped on medium speed. Other speeds require eld selection.
CT ECM: Units factory shipped on Speed Tap 2 for Fan-Only and Speed Tap 3 for Heating/Cooling.
All airow is rated and shown above at the lower voltage if unit is dual voltage rated, e.g. 208V for 208-230V units.
Only two speed PSC fan (H & M) available on 575V units.
Performance stated is at the rated power supply. Performance may vary as the power supply varies from the rated.
All data is shown wet coil with clean 1” lter.
All data is ran at 80 °F DB and 67 °F WB.
CFM Tolerance is 7%.
RPM/Watt Tolerance 10%.
