Blower Performance Data – TC006
Rated
CFM
Min CFM
Motor
Type
Motor Speed
Setting
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
225 150 PSC
Low CFM 210 190 160
Medium CFM 260 240 210 190
High CFM 310 290 270 230 180
225 150
ECM -
Constant
Torque
1
RPM 944 1028 1114 1206 1297
Power (W) 22 24 25 28 30
CFM 225 207 187 169 150
2
RPM 1201 1280 1362 1441 1523 1608 1694
Power (W) 34 37 39 42 44 48 51
CFM 233 217 201 185 173 164 150
3
RPM 1324 1400 1476 1551 1628 1709 1786
Power (W) 43 45 48 51 54 58 61
CFM 241 227 212 200 188 179 168
4
RPM 1516 1588 1658 1730 1799
Power (W) 55 58 61 65 67
CFM 240 227 216 205 193
225 150
ECM -
Constant
Volume
Minimum CFM
RPM 763 933 1078 1201 1314 1417 1519 1615 1712
Power (W) 16 21 27 40 36 41 46 52 59
CFM 150 150 150 150 150 150 150 150 150
Default CFM
RPM 983 1102 1211 1319 1419 1516 1610 1708 1783 1817
Power (W) 29 35 41 47 53 60 67 76 81 77
CFM 225 225 225 225 225 225 225 225 225 255
Maximum CFM
RPM 1053 1162 1265 1366 1462 1553 1648 1733 1802 1817
Power (W) 35 41 47 53 60 67 76 84 88 78
CFM 250 250 250 250 250 250 250 250 250 250
See ECM control section for details on setting airow.
Airow is controlled within 5% up to the Max ESP shown with wet coil.
Do not select Dehumidication mode if HP CFM is on setting 1.
ClimaDry is factory wired to operate in stage 2 airow.
Black areas denote ESP where operation is not recommended.
PSC: Units factory shipped on medium speed. Other speeds require eld selection.
CT ECM: Units factory shipped on Speed Tap 2 for Fan-Only and Speed Tap 3 for Heating/Cooling.
All airow is rated and shown above at the lower voltage if unit is dual voltage rated, e.g. 208V for 208-230V units.
Only two speed PSC fan (H & M) available on 575V units.
Performance stated is at the rated power supply. Performance may vary as the power supply varies from the rated.
All data is shown wet coil with clean 1” lter.
All data is ran at 80 °F DB and 67 °F WB.
CFM Tolerance is 7%.
RPM/Watt Tolerance 10%.
