ClimateMaster Tranquility TCH 024 - TC Series Wiring Diagram Matrix

ClimateMaster Water-Source Heat Pumps
52
CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
Compact (TC) Series
Rev.: July 7, 2020
TC Series Wiring Diagram Matrix
All current diagrams can be located online at climatemaster.com/commercial-wiring
DESCRIPTION Voltage: G.E Voltage: H Voltage: F Voltage: N
WIRE DIAGRAMS TC006, 009, 0112
TC015, 018, 024, 030,
036, 042, 048, 060, 041
TC024, 030, 036, 042,
048, 060, 041
TC024, 030, 036, 042,
048, 060, 041
TC042, 048, 060, 041
CXM / /PSC 96B0450N10 96B0450N15 96B0450N20 96B0450N30 96B0450N30
CXM / LON / PSC 96B0450N11 96B0450N16 96B0450N21 96B0450N31 96B0450N31
CXM / MPC / PSC 96B0450N12 96B0450N17 96B0450N22 96B0450N32 96B0450N32
DXM2 / / PSC 96B0466N01 96B0466N11 96B0466N21 96B0466N31 96B0466N31
DXM2 / LON / PSC 96B0466N02 96B0466N12 96B0466N22 96B0466N32 96B0466N32
DXM2 / MPC / PSC 96B0466N03 96B0466N13 96B0466N23 96B0466N33 96B0466N33
DXM2 / / ECM - CV 96B0467N01 96B0467N11 96B0467N21 96B0467N31
DXM2 / LON / ECM - CV 96B0467N02 96B0467N12 96B0467N22 96B0467N32
DXM2 / MPC / ECM - CV 96B0467N03 96B0467N13 96B0467N23 96B0467N33
CXM / / ECM - CT 96B0454N01 96B0454N11 96B0454N21 96B0454N31
CXM / LON / ECM - CT 96B0454N02 96B0454N12 96B0454N22 96B0454N32
CXM / MPC / ECM - CT 96B0454N03 96B0454N13 96B0454N23 96B0454N33
DXM2 / / ECM - CT 96B0468N01 96B0468N11 96B0468N21 96B0468N31
DXM2 / LON / ECM - CT 96B0468N02 96B0468N12 96B0468N22 96B0468N32
DXM2 / MPC / ECM - CT 96B0468N03 96B0468N13 96B0468N23 96B0468N33
CXM / /
/ WSE
96B0452N10 96B0452N15 96B0452N20 96B0452N30 96B0452N30
DXM2 / /
/ WSE
96B0476N01 96B0476N11 96B0476N21 96B0476N31 96B0476N31
DXM2 / LON /
/ WSE
96B0476N02 96B0476N12 96B0476N22 96B0476N32 96B0476N32
DXM2 / MPC /
/ WSE
96B0476N03 96B0476N13 96B0476N23 96B0476N33 96B0476N33
DXM2 / / ECM - CV
/ WSE
96B0477N01 96B0477N11 96B0477N21 96B0477N31
DXM2 / LON / ECM - CV
/ WSE
96B0477N02 96B0477N12 96B0477N22 96B0477N32
DXM2 / MPC / ECM - CV
/ WSE
96B0477N03 96B0477N13 96B0477N23 96B0477N33
CXM / / ECM -
CT / WSE
96B0455N01 96B0455N11 96B0455N21 96B0455N31
DXM2 / / ECM - CT
/ WSE
96B0478N01 96B0478N11 96B0478N21 96B0478N31
DXM2 / LON / ECM - CT
/ WSE
96B0478N02 96B0478N12 96B0478N22 96B0478N32
DXM2 / MPC / ECM - CT
/ WSE
96B0478N03 96B0478N13 96B0478N23 96B0478N33
