FIGURE B-7. PNEUMATIC CONNECTION ASSEMBLY (P/N 15088)
ASSEMBLED
SCALE 1 : 15
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
HOSE 801 SERIES PUSHLOK 1/21031070IN1
HOSE 801 SERIES PUSHLOK 1/21031016IN2
FTG BARB 1/2 NPTM X 1/2 HOSE1031143
FTG REDUCER BUSHING 1 NPTM X 1/2NPTF
1032114
FTG QUICK COUPLER 1/2B 1/2NPTF FEMALE AIR
132082
5
FTG QD NIPPLE 1/2B 1/2 NPTM PNEUMATIC
1320926
MUFFLER AIR MOTOR
152431
7
EXHAUST DEFLECTOR
1973018
VALVE BALL 1/2 NPTM X 1/2 NPTF OVAL HANDLE
3566719
FTG ELBOW 1/2 NPTM X 1/2 NPTF ST 90 DEG BRASS
35692110
FTG QUICK COUPLER 1B 1 NPTF FEMALE AIR BRASS
55800111
FTG QUICK COUPLER 1B 1 NPTM MALE AIR NON-VALVED BRASS
55801112
FTG TEE 1 NPTF (3) BRASS
55802113
FTG BARB 1 NPTM X 1 HOSE BRASS
55803214
FTG CONNECTOR 1 NPTF X 1NPTF BRASS55804115
HOSE PUSH LOK 801 X 1 GREY5580560IN16
FTG ELBOW 1 NPTM X 1 NPTM 90 DEG55832117
FTG QUICK COUPLER UNIVERSAL 1 NPTM58380118
PNEUMATIC CONDITIONING UNIT 1 IN W/ L.P. DROP OUT AND E-STOP CE59248119
FTG QUICK COUPLER UNIVERSAL 1/2 NPTF
62564120
2
13
12
10
3
16
19
AIR MOTOR
(REFERENCE ONLY)
7
15
14
14
4
17
11
5
3
8
6
5
9
3
1
3
20
18
