FIGURE B-9. SETUP CONE ASSEMBLY (P/N 26383)
26507
SET CONE SETUP 2.75 TO 8.37 DIA BB5000
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
CONE SETUP Ø2.75 TO Ø8.37 BB5000
2638011
SCREW MOD 3/8-24 X 1-3/16 SSSFD
2909211.1
PIN STOP
2909111.2
CLAMP COLLAR MODIFIED2909513
SCREW 5/16-24 X 1-1/2 SHCS1712523.1
1.1
1.2
1
3.1
3
