FIGURE B-25. SERVO SHROUD FAN ASSEMBLY (P/N 56773)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
WASHER 1/4 FLTW SAE
1070221
SCREW 1/4-20 X 1-3/4 SHCS
1325222
(NOT SHOWN) MOUNTING BASE WIRE TIE ADHESIVE BACKED LARGE
1329613
SCREW 1/4-20 X 1-1/2 BHSCS
1900124
(NOT SOWN) TUBE SHRINK .125 DIA BLACK
228002 IN5
NUT 8-32 LOCKING STAR WASHER28617
4
6
HANDLE PULL 1/4 CBORE MTG 2.0 X 5.12 X 1.02W PLASTIC COATED534621
7
SHROUD FAN BB5000 RDU SERVO5658718
RECEPTACLE MICROFAST 3 POLE MALE 1/4 NPT THD 0.5M LONG CONDUCTORS5675719
SPACER ROUND .252 ID X .625 OD X .75 ALUMINUM56767410
SCREW 8-32 X 1-1/2 BHSCS
56771411
WASHER #8 FLTW RUBBER .93 THICK
56772412
FAN 4.69" SQUARE X 1" 24 VDC 80CFM
56774113
GUARD FAN STEEL WIRE 4.13" SQUARE BOLT PATTERN
56775114
2
7
10
9
6
12
1
4
13
10
1
4
8
14
11
