Climax BB5000 - Able B-3. Hydraulic Metric Spare Parts

P/N 92974, Rev. 1 Page 115
28687 ASSY LEADSCREW 24 INCH FEED 1
28688 ASSY LEADSCREW 36 INCH FEED 1
TABLE B-3. HYDRAULIC METRIC SPARE PARTS
Part
number
Description Quantity
10191 SCREW 3/8-16 X 1 SHCS 2
11691 SCREW 1/2-13 X 1-1/2 SHCS 2
11734 SCREW 3/8-16 X 3/4 SSSCP 4
13356 SCREW 5/8-11 X 2-1/2 SHCS 4
14036 SCREW 1/2-13 X 2 SHCS 8
21798 WASHER 5/16 FLTW HARDENED 1/8 THK BLK OX 4
22662 WASHER 1/2 FLTW HARDENED 1-1/8 OD X 1/8 THICK 8
25957 BRG ROLLER CLUTCH 1 ID X 1.312 OD X .625 4
26250 SCREW 5/16-24 X 2 HHCS 4
26252 SCREW 1/2-20 X 2 SSSFP 4
26850 HANDLE CRANK MODIFIED 1
27015 SP PIN DOWEL MODIFIED .187 DIA X .75 GROOVED 2
27197 LEAD NUT BB4500 BB5000 AXIAL FEED 2
92494 SCREW ASSY FEED STOP GEN 2 2
27356 NUT 1-5 ACME 7/8 TALL 1-1/2 HEX FINISHED 2
29207 SPRING PLUNGER HAND RETRACT 1/2 X 13 2
33999 WRENCH HEX SET .050 - 3/8 BONDHUS BALL END 1
34571 BIT TOOL HSS 12MM X 4.0 LH FINISH SINGLE TC 4
34572 BIT TOOL HSS 12MM X 2.5 LH FINISH SINGLE TC 4
34573 BIT TOOL HSS 12MM X 1.8 LH FINISH SINGLE TC 4
34576 BIT TOOL HSS 12MM X 4.0 LH ROUGHING SINGLE 4
34577 BIT TOOL HSS 12MM X 2.5 LH ROUGHING SINGLE 4
34578 BIT TOOL HSS 12MM X 1.8 LH ROUGHING SINGLE 4
34642 SCREW M16 X 1.5 X 8 SSSFP 24
38678 WRENCH HEX SET 1.5 - 10MM BONDHUS BALL END 1
TABLE B-2. LEADSCREW SPARE PARTS (CONTINUED)
Part
number
Description Quantity
