3 SETUP
IN THIS CHAPTER:
3.1 RECEIPT AND INSPECTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -31
3.2 L
IFTING AND RIGGING - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -32
3.3 M
ACHINE ASSEMBLY - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -32
3.3.1 B
AR AND MOUNTING BRACKET ASSEMBLY - - - - - - - - - - - - - - - - - - - - - - - - - - - -33
3.3.2 T
OOLING AND TOOL HEAD ASSEMBLY - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -35
3.3.2.1 P
LACING THE TOOL BIT INTO THE BAR - - - - - - - - - - - - - - - - - - - - - - - - - - -36
3.3.2.2 P
LACING THE TOOL HEAD ONTO THE BORING HEAD - - - - - - - - - - - - - - - - - - - - -36
3.3.3 RDU
AND AFU ASSEMBLY - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -37
3.4 A
XIAL FEED - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -40
3.4.1 S
ELECTING THE FEED DIRECTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -40
3.4.2 S
ETTING THE FEED RATE - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -41
3.4.3 A
UTOMATIC FEED STOP - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -42
3.5 P
OWER CONNECTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -43
3.5.1 H
YDRAULIC MACHINES - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -43
3.5.2 BB5000
SERVO DRIVE MACHINE - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -44
3.5.3 E
LECTRICAL MACHINES - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -46
3.5.4 P
NEUMATIC MACHINES - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -46
3.6 BB4500-BB5000
WITH SMALL DIAMETER BARS - - - - - - - - - - - - - - - - - - - - - - - - - - - - -47
This section describes the setup and assembly procedures for the BB4500-BB5000
boring machine.
3.1 RECEIPT AND INSPECTION
Your CLIMAX product was inspected and tested prior to shipment, and packaged
for normal shipment conditions. CLIMAX does not guarantee the condition of
your machine upon delivery.
When you receive your CLIMAX product, perform the following receipt checks:
1. Inspect the shipping containers for damage.
2. Check the contents of the shipping containers against the included invoice
to make sure that all components have been shipped.
3. Inspect all components for damage.
5Contact CLIMAX immediately to report damaged or missing components.
NOTICE
Keep the shipping container and all packing materials for future storage
and shipping of the machine.
