Climax BB5000 - Arge and Small Set Cones Assembly

P/N 92974, Rev. 1 Page 77
F
IGURE A-12. LARGE AND SMALL SET CONES ASSEMBLY (P/N 49060)
SET CONES SETUP 6 TO 10 DIA 1-3/4 KEYED BAR
43384
SET CONES SETUP 2 TO 6 DIA 1-3/4 KEYED BAR
43383
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
CONE SETUP 6 TO 10 BB4500 1-3/4 BAR
4222811
SCREW MOD 3/8-24 X 1-3/16 SSSFD
2909211.1
PIN STOP
2909111.2
CONE SETUP BB4000 6" TO 10"4222811.3
CLAMP COLLAR MODIFIED 1 3/4 ID 4250812
CLAMP COLLAR MODIFIED4250812.1
SCREW 5/16-24 X 1-1/2 SHCS1712522.2
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
CONE SETUP 2 TO 6 BB4500 1-3/4 BAR
4122011
SCREW MOD 3/8-24 X 1-3/16 SSSFD
2909211.1
PIN STOP
2909111.2
CONE SETUP 2" TO 6" BB4000
4122011.3
CLAMP COLLAR MODIFIED 1 3/4 ID
4250812
CLAMP COLLAR MODIFIED
4250812.1
SCREW 5/16-24 X 1-1/2 SHCS1712522.2
2.2 1.1
1.2 1.3
2.1
2.2
2.1
1.1 1.2
1.3
