Page 28 BB4500-BB5000 Operating Manual
2.6.1 Electrical specifications
CLIMAX electrical equipment is suitable for use in the physical environment and
operating conditions specified below. When the physical environment or the oper-
ating conditions are outside those specified, consult CLIMAX before putting the
electrical equipment into service.
TABLE 2-20. ELECTRICAL SPECIFICATIONS
Mains voltage (AC): ±10% of nominal
Mains frequency (AC): ±1% of nominal
Mains harmonics:
10% of RMS volts
2nd through 30th harmonic
Voltage imbalance (3-phase supplies): 2% maximum
Voltage impulses:
200% of nominal
1.5 milliseconds (ms) maximum duration
Voltage interruption: 3 ms maximum with 1 second between
Voltage dip (brownout): 20% of peak volts for 1 second maximum
Voltage supplied from batteries: ±10% of nominal
Voltage interruption (DC): 5 ms maximum
Ambient temperature (operating): 41–104°F (5–40°C)
Ambient temperature (transport and
storage):
-13–131°F (-25–55°C)
Relative humidity: 20–95% non-condensing
Altitude: 6,600 ft (2,000 m)
Contaminants:
IP54 environment except for some motors
and slip ring assemblies that are IP 20
Available fault current:
Not greater than that listed on the controls
nameplate
Vibration
Pushbuttons: 5g at 5–300 Hz
Relays, contactors, and breakers: 2g at 5–300 Hz
Touchscreen HMI: 1g at 9–150 Hz
Servo amplifiers and PLC: 1g at 9–150 Hz
Physical shock (impact)
Pushbuttons: 30g for 18ms
Relays, contactors, and breakers: 6g for 11ms
Touchscreen HMI: 15g three times in X, Y, and Z
Servo amplifiers and PLC: 1g three times in X, Y, and Z
