Climax BB5000 - Igure A-10. Universal Mount Assembly (P;N 43267)

P/N 92974, Rev. 1 Page 75
F
IGURE A-10. UNIVERSAL MOUNT ASSEMBLY (P/N 43267)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
SCREW 1/2-13 X 7 SHCS
1122341
SCREW 1/2-13 X 5 SHCS
1187942
WASHER 5/16 FLTW SAE
1348943
SCREW 1/2-13 X 2 SHCS
1403644
WASHER 1/2 FLTW HARDENED 1-1/8 OD X 1/8 THK
226624
5
SCREW 1/2-20 X 3/4 SSSFP
2727346
BEARING MOUNT RING 1-3/4
3696217
EXTENSION ARM MOUNT36965
4
8
TACK BLOCK 4 IN36966
4
9
ASSY STAND OFF TUBE 3.3 INCH37598
4
10
ASSY STAND OFF TUBE 5.3 INCH37599411
MOUNT BRG SPHERICAL 1-3/4 ID W/CLAM STD43264112
SCREW 5/16-24 X 1.500 HHCS FLANGED BLK OX
45365413
10
2
8
12
4
7
9
5
1
6 13 3
11
13
