Page 68 BB4500-BB5000 Operating Manual
FIGURE A-3. BORING HEADS SET ASSEMBLY (P/N 43576)
TOOL HEAD METRIC 4 TO 6 DIA 1-3/4 BAR BB4500
43563
TOOL HEAD METRIC 6 TO 8 DIA 1-3/4 BAR BB4500
43564
TOOL HEAD METRIC 8 TO 10 DIA 1-3/4 BAR BB4500
43565
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
SCREW M8 X 1.25 X 12mm SSSCP
3521421
SCREW M12 X 1.75 X 30mm SHCS
4069722
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
SCREW M12 X 1.75 X 30mm SHCS4069721
SCREW M8 X 1.25 X 12 SSSFP4312032
PARTS LIST
DESCRIPTIONP/N:QTYITEM
SCREW M8 X 1.25 X 12mm SSSCP
3521431
SCREW M12 X 1.75 X 30mm SHCS
4069722
1
2
2
1
1
2
