Climax BB5000 - Specifications

P/N 92974, Rev. 1 Page 27
2.6 SPECIFICATIONS
TABLE 2-17. BB4500-BB5000 BORING BAR DIMENSION IDENTIFICATION
Number Component
1 Stroke
2 Workpiece: distance between outer edges of the workpiece = X
TABLE 2-18. SUB-COMPONENT MASS
Component Mass in lbs (kg)
Motor: 43 lbs (20 kg)
Adapter assembly (P/N 51536): 10 lbs (5 kg)
Rotational drive unit (P/N 53165): 31 lbs (14 kg)
Total for motor, adapter assembly and RDU: 85 lbs (39 kg)
Pendant: 4 lbs (2 kg)
HPU – 10 HP: 695 lbs (315.2 kg)
Machine total weight (including single arm
mounts, setup cones, and hydraulic motor):
444 lbs (201 kg)
Approximate boring bar ship weight (including
the metal shipping container):
1.48 lbs/inch
(0.264 kg/cm)
TABLE 2-19. BORING SPECIFICATIONS
Component BB4500 range BB5000 range
Boring bar diameter (standard): 1.75" (45 mm) 2.25" (57 mm)
Boring bar diameter (optional): 1.25" (32 mm)
1.75" (45 mm)
1.25" (32 mm)
Boring diameter (standard): 2–10" (51–254 mm) 2.5–12" (64–305 mm)
Boring diameter (optional): 1.5–5" (38–127 mm) 1.375–24" (35 – 610 mm)
Boring stroke (standard): 12" (305 mm) 12" (305 mm)
Boring stroke (optional): 36" (914 mm)
24 (610 mm)
36" (914 mm)
