Climax BB5000 - Igure A-11. Double Arm Bearing Mount Assembly (P;N 43279)

Page 76 BB4500-BB5000 Operating Manual
FIGURE A-11. DOUBLE-ARM BEARING MOUNT ASSEMBLY (P/N 43279)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
WASHER 5/16 FLTW SAE13489
4
1
SCREW 1/2-13 X 2 SHCS1403682
WASHER 1/2 FLTW HARDENED 1-1/8 OD X 3/16 THK1714583
SCREW 5/16-18 X 1-3/4 SSSFP2017444
MOUNT BRG SPHERICAL 1-3/4 ID W/CLAM STD
432641
5
PLATE BEARING SCAB
4326626
BRACKET MOUNTING DOUBLE ARM
432771
7
SCREW 5/16-24 X 1.500 HHCS FLANGED BLK OX
4536548
6
8
1
3
2
5
3
2
4
7
