Climax BB5000 - BB5000 Servo Motors

P/N 92974, Rev. 1 Page 19
Refer to the correct “Maximum bar RPM” column in Table 2-6 for hydraulic motor
performance.
2.4.2 BB5000 servo motors
NOTICE
Never disconnect any cable from this machine without first turning off
the mains disconnect switch. Interrupting the connection between the
servo amplifier and the servo motor while they are energized may
damage the servo amplifier, even if the motor is stopped. Failure to
comply with this warning will void the warranty on the control system.
TABLE 2-6. HYDRAULIC MOTOR SPECIFICATIONS
Motor capacity
Maximum bar RPM
Torque at
bar
Part number
for motors with
60 series QD
fittings
Part number
for motors with
ISO 16028 QD
fittings
8.36 gpm
(31.5 L/min)
1
10 gpm (37.9
L/min)
2
2.2 inch
3
(36 cm
3
) 204 246
92 ft-lbs
(124.7 Nm)
39837 65384
3.6 inch
3
(59 cm
3
) 124 150
159 ft-lbs
(215.6 Nm)
39843 63425
5.7 inch
3
(93.4 cm
3
) 76 92
270 ft-lbs
(367 Nm)
39844 63429
7.3 inch
3
(119.6 cm
3
) 60 73
342 ft-lbs
(463.7 Nm)
39845 69434
8.9 inch
3
(145.8 cm
3
) 49 60
417 ft-lbs
(565.4 Nm)
39846 69435
11.3 inch
3
(185.2 cm
3
) 40 49
478 ft-lbs
(648.1 Nm)
43451 69436
14.1 inch
3
(231.1 cm
3
) 31 38
652 ft-lbs
(884.0 Nm)
39847 39847
17.9 inch
3
(293.3 cm
3
) 24 30
764 ft-lbs
(1,035.8 Nm)
43452 69439
1. With 50 Hz mains power.
2. With 60 Hz mains power.
