CMC CAPTO - Field of Application; Nomenclature; Standards & Certifications

8 | CMCPRO.COM
| CAPTO USER MANUAL 9
Standards & Certifications
1
Pulley strength testing performed by using CAPTO Becket as Pulley Attachment Point
2
FIELD OF APPLICATION
SEE TEXT
3
NOMENCLATURE
A Moving Sideplate
B Sideplate Release Button
C Sideplate Latch
D Cam
E Cam Grip
F Rear Rope Guide
G Front Rope Guide
H Pulley
I Becket
J Accessory Loop Attachment
K Anchor/Load End
Standard Allowable Rope
Type(s)
Diameter
Range
Rating / Max
Load
NFPA 2500 Rope Grab CI1801 Static Rope Ø 10.5-11 mm G-Rated
NFPA 2500 Pulley N/A Ø 13mm MAX G-Rated
1
EN 12841:2006/B EN 1891-A Ø 10.5-11 mm 200 kg
EN 567:2013 EN 1891 – EN 892 Ø 10.5-11 mm N/A
EN 12278:2007 EN 1891 – EN 892
– EN 564
Ø 13mm MAX 36kN (18+18)
1
