Chapter 4: Using the web interface
98-129217-D Site map 121
2. Click Self test.
3. Click OK in the Warning dialogue.
The terminal now reboots and performs a self test.
Extended status
To see the Extended status page, select HELPDESK > Extended status.
To view updated information on the Extended status page, click Refresh.
The Extended Status page shows the following information:
• The antenna Product ID (must always be TT-3050C).
• The status of the connection to the air interface (IAI-2). This field should normally show
“Registered”, unless the system is still in the startup process.
• Ongoing data sessions (IP address) and connection status, e.g. Active or Suspended.
• Ongoing calls and their connection status.
Site map
The web interface also offers a site map page. Use this page to get an overview of the
submenus.
To access the site map, select SITE MAP from the left navigation pane.
Click on items in the site map to go directly to the relevant location.
