Safety summary 1
The following general safety precautions must be observed during all phases of operation, service
and repair of this equipment. Failure to comply with these precautions or with specific warnings
elsewhere in this manual violates safety standards of design, manufacture and intended use of the
equipment. Thrane & Thrane A/S assumes no liability for the customer's failure to comply with
these requirements.
Observe marked areas
Under extreme heat conditions do not touch areas of the terminal or
antenna that are marked with this symbol, as it may result in injury.
Microwave radiation hazards
During transmission the antenna in this system radiates Microwave
Power.This radiation may be hazardous to humans close to the antenna.
During transmission, make sure that nobody gets closer than the recommended minimum safety
distance.
On the SAILOR 150 FleetBroadband, the minimum safety distance to
the antenna panel on the focal line is 0.6 m, based on a radiation level of
10 W/m
2
. The radiation level is 100 W/m
2
at a distance of 0.2 m from the
antenna panel. Refer to the drawing below.
Pour une antenne SAILOR 150 FleetBroadband, la distance de
sécurité minimale avec le panneau de l'antenne sur l'axe focal est de
0.6 m, sur la base d'un niveau de radiation émis de 10 W/m
2
. L'appareil génère un niveau de
radiation de 100 W/m
2
à une distance de 0.2 m de l'avant du panneau de l'antenne. Veuillez
consulter le schéma au-dessous.
Distance to other equipment
Do not move the antenna closer to radars than the min. safe distance specified in the installation
manual - it may cause damage to the antenna.
MICROWAVE RADIATION
No personnel within safety distance
60
Safety distance:
(0.2 m, 100 W/m
2
)
0.6 m, 10 W/m
2
