C001537_04_CR2 User Manual - 39
Save Settings
5.6.5 - RS232 Batch Mode Considerations
In RS-233 Cabled mode, the CR2 thinks it is always connected even though the serial cable is
disconnected or the power adapter is unplugged. Data scanned will be sent, regardless of connection
status. Data scanned in Cabled mode will be lost if the CR2 is not connected to the serial cable-it will
not buffer the data.
Also, no log features work while the CR2 is in RS232 cabled mode.
In RS232 Batch mode, the CR2 will detect if it is connected to a powered serial cable, and will send
the data. If a powered serial cable is not connected or if the power adapter is not connected to the
serial cable, the CR2 will buffer the data. When the CR2 is then connected to a powered serial cable,
the data will automatically upload.
Important Note: If you are in RS232 Batch mode (default settings), when you place a unit in a charger
the reader will think it is cabled and download the data. The data will be erased from memory. Please
scan Disable Auto Transfer Buffer Memory code above as a solution to this issue.
All log mode features work in RS232 Batch mode.
RS232 Batch RS232 Cabled
5.6.3 - RS232 Interface - Baud Rate
Scan the following codes to set the appropriate baud rate:
1200 2400 4800 9600
19200 38400 57600 (Default) 115200
5.6.4 - RS232 Interface - Parity
Scan the following codes to set parity:
Even Odd None (Default)
