C001537_04_CR2 User Manual - 66
Save Settings
11.5 - Frequently Asked Questions
What can I do if my CR2 will not read a code?
1. Make sure the code is enabled, as not all codes are enabled by default.
2. Check to see you are the appropriate distance from the code by checking the
decode zone diagram on page 8 of the User’s Manual.
3. Make sure the code is not smeared.
4. See chapter 8 to configure reader for longer decode times or for non-standard inks.
5. Take image of code using the Image Uploader software located at:
http://www.codecorp.com/support/downloads.htm. Send the image to Code
Technical support at support@codecorp.com.
11.4 - CR2 Accessories (con’t)
Optional Accessories
The following accessories are also available by contacting a Code representative:
• USB, PS/2 or RS232 interface cables (Figure 11.2)
• 1400 mAH or 1950 mAH Long-life Lithium-Ion batteries (Figure 11.3)
•. Clip-on pistol grip handle (Figure 11.4)
• Class 1 Bluetooth radio (300 foot operating range)
• 2 slot external battery charger (Figure 11.5)
• CodeXML Bluetooth modem
• CodeXML Router software
• Durable cover for CR2
Figure 11.2 RS232 Cable Interface
Figure 11.3 Long Life Battery
Figure 11.4 Pistol Grip Handle
Figure 11.5 External Battery Charger
