C001537_04_CR2 User Manual - 54
Save Settings
Transfer Only Unsent Data in Memory Delete Scanned Data from Memory
Enable Auto Transfer Buffer Memory (Default) Disable Auto Transfer Buffer Memory
RS232 Considerations
In RS-233 Cabled mode, the CR2 will behave as it is always connected even though the serial cable is
disconnected or the power adapter is unplugged. Data scanned will be sent, regardless of connection status.
Data scanned in Cabled mode will be lost if the CR2 is not connected to the serial cable-it will not buffer the
data, unless Send & Log mode has been enabled.
In RS232 Batch mode, the CR2 will detect if it is connected to a powered serial cable, and will send the
data. If a powered serial cable is not connected or if the power adapter is not connected to the serial cable,
the CR2 will buffer the data. When the CR2 is then connected to a powered serial cable, the data will
automatically upload.
Important Note: If you are in RS232 Batch mode (default settings), when you place a unit in a charger your
reader will behave as it is cabled and download the data. The data will be erased from memory. Please scan
Disable Auto Transfer Buffer Memory code above as a solution to this issue.
RS232 Batch (Default) RS232 Cabled
8.1 - Batch Mode (con’t)
CR2 has a time stamp feature for logging data (The time stamp is defaulted off in shipped units). If you
enable the time stamp feature, everytime the CR2 is powered off or rebooted, the timer will stop.
A 8-digit number represents the time stamp. The format is ddhhmmss (dayday/hourhour/minuteminute/sec-
ondsseconds). Scan the following codes to turn the time-stamp on/off:
On Off (Default)
Note: The time stamp feature is in relative time from when the reader was last powered up.
8.2 - Time Stamp Settings
Note: Not applicable in “Log Only Mode”
use “Transfer All Data In Memory”.
