ComAp InteliLite 4 AMF 20 User Manual

7 Technical data
Power supply range
8-36 VDC
Power consumption
(without modules)
3.5W
RTC battery
Replaceable (3V)
Fusing power
4 A w/o BOUT consumption
E-Stop fusing
10 A
Max. Power Dissipation
9 W
Power supply
Protection degree (front
panel)
IP 65
Operating temperature
-20 ˚C to +70 ˚C
Storage temperature
-30 ˚C to +80 ˚C
Operating humidity
95 % non-condensing
(EN 60068-2-30)
Vibration
5-25 Hz, ± 1.6 mm
25-100 Hz, a = 4 g
Shocks
a = 500 m/s
2
Surrounding air temperature rating 70 °C
Suitable for pollution degree 2
Operating conditions
Max. output current
250 mA
Charging fail threshold
Adjustable
D+
Measurement inputs
3ph-n Gen voltage , 3ph-n Mains
Measurement range
10-277VAC / 10-480VAC (EU)
10-346V AC/ 10-600VAC
(US/Canada)
Linear measurement
and protection range
350V AC Ph-N
660VAC Ph-Ph
Accuracy
1 %
Frequency range
30-70 Hz (accuracy 0.1 Hz)
Input impedance
0.72 MΩ ph-ph , 0.36 MΩ ph-n
Voltage measurement
Isolation
Isolated
Type
max ±10VDC
Voltage regulator output
Isolation
Non-isolated
Output Type
±10VDC or 5V @ 500 Hz,
PWMselectableby jumper
Speed governor output
Type
Build-in monochromatic 3.2"
Resolution
132 × 64px
Display
USB Device
Non-isolated type B connector
USB Host
Non-isolated type A connector
CAN 1
Non-isolated, 250 / 50 kbps,
Terminator impedance 120 Ω
Communications
Measurement inputs
3ph Gen current
Measurement range
5 A
Max. allowed current
10 A
Accuracy
±20 mA for 0-2 A; 1 % of value for 2-5 A
Input impedance
<0.1 Ω
Current measurement
Dedicated terminal for safe E-Stop input.
Physical supply for binary outputs 1 & 2.
E-Stop
Number
6
Close/Open indication
0-2 VDC close contact
6-36 VDC open contact
Binary inputs
Number
6
Max. current
BO1,2=5A (60°C); BO1,2=4A (70°C),
BO3-6=0.5A
Switching to
positive supply terminal
Binary outputs
Number 3, switchable (R/U/I)
Range R = 0-2500 Ω; U = 0-10 V; I = 0-20 mA
Accuracy
R: ±2% from value ±5 Ω in range 0-250 Ω
R: ±4% from value in range 250 Ω-2500 Ω
U: 1% from value ±100 mV
I: 1% from value ±0.2 mA
Analog inputs
Max. current
45mA
+5V Power supply output
Voltage input
range
4 Vpk-pk to 50 Vpk-pk in range 4 Hz to 1 kHz
6 Vpk-pk to 50 Vpk-pk in range 1 to 5 kHz
10 Vpk-pk to 50 Vpk-pk in range 5 to 10 kHz
Frequency input
range
4 Hz to 10 kHz
Frequency
measurement
tolerance
0.2 % from measured value
Magnetic pickup
