InteliLite4 AMF20 Global Guide
399
ECU-AIN-EXT-2
Value group Engine Related FW 1.3.0
Units Depends on ECU value
Comm object 10174 Related applications AMF,MRS
Description
This is one of the inputs, which are defined by ECU. Order of values depends on type of ECU.
Note: Usually there are engine speed[RPM], fuel rate[L/h], coolant temperature[°C], intake
temperature[°C], oil pressure[bar], boost pressure[bar], load[%], oil temperature[°C] etc.
6 back to List of values
Speed Request
Value group Engine Related FW 1.3.0
Units %
Comm object 10137 Related applications AMF,MRS
Description
This value contains the speed control signal expressed in %.
Speed request Requested speed Accelerator pedal position
0% 1350 RPM 0%
50% 1500 RPM 50%
100% 1650 RPM 100%
Note: Accelerator pedal position will be 0 if the engine is not running or loaded.
6 back to List of values
Requested RPM
Value group Engine Related FW 1.3.0
Units RPM
Comm object 10006 Related applications AMF,MRS
Description
This value contains the speed which is currently requested by the controller from the attached ECU.
This value is used for digital interfacing (via a communication bus) with ECUs that require the requested
speed directly in RPM.
6 back to List of values
DPF Soot Load
Value group Engine Related FW 1.3.0
Units %
Comm object 12484 Related applications AMF,MRS
Description
Indicates the soot load percentage of diesel particulate filter (DPF).
6 back to List of values
