InteliLite4 AMF20 Global Guide
184
Message structure:
Controller
-----------------------------------------------
Name: XXX
Serial number: XXX
SW branch: XXX
SW version: XXX
Application: XXX
Appl. version: XXX
Date: dd/mm/yyyy
Time: hh:mm:ss
Alarm list
-----------------------------------------------
Alarm 1
Alarm 2
Alarm 3
History events
-----------------------------------------------
0 dd/mm/yyyy hh:mm:ss.0 Event 1
-1 dd/mm/yyyy hh:mm:ss.0 Event 2
-2 dd/mm/yyyy hh:mm:ss.0 Event 3
Note: An asterisk means that alarm is unconfirmed and an exclamation mark means that alarm is active.
6.2 Connection to 3rd party systems
6.2.1 SNMP 184
6.2.2 MODBUS-RTU, MODBUS/TCP 186
6 back to Communication
6.2.1 SNMP
SNMP is an UDP-based client-server protocol used for providing data and events into a supervisory system
(building management system). The controller plays the role of a "SNMP Agent" while the supervisory system
plays the role of a "SNMP Manager".
CM3-Ethernet module is required for SNMP function
Supported versions – SNMP v1 and SNMP v2
The SNMP Agent function is to be enabled by the setpoint SNMP Agent (page 362) in the CM-Ethernet
setpoint group. The setpoints SNMP RD Community String (page 363) and SNMP WR Community String
(page 363) in the same group can be used to customize the "community strings" for the read and write
operations which function like "passwords". All requests sent from the SNMP Manager must contain a
