InteliLite4 AMF20 Global Guide
61
5 Controller setup
5.1 Default configuration 61
5.2 Controller configuration and PC tools connection 62
5.3 Operator Guide 71
5.4 Remote Display 95
5.5 Functions 100
5.6 User management and data access control 164
6 back to Table of contents
5.1 Default configuration
5.1.1 Binary inputs
Number Description Configured function
BIN1 Generator circuit breaker feedback GCB FEEDBACK (PAGE 450)
BIN2 Mains circuit breaker feedback MCB FEEDBACK (PAGE 453)
BIN3 Not used Not Used
BIN4 Not used Not Used
BIN5 Switch controller to OFF mode REMOTE OFF (PAGE 458)
BIN6 Switch controller to TEST mode REMOTE TEST (PAGE 460)
5.1.2 Binary outputs
Number Description Function
BOUT1 Starter motor control STARTER (PAGE 501)
BOUT2 Fuel solenoid valve FUEL SOLENOID (PAGE 477)
BOUT3 Indication of breaker state GCB CLOSE/OPEN (PAGE 480)
BOUT4 Indication of breaker state MCB CLOSE/OPEN (PAGE 490)
BOUT5 Activation of any devices before start PRESTART (PAGE 496)
BOUT6 Gen-set can be connected to load READY TO LOAD (PAGE 498)
5.1.3 Analog inputs
Number Configured sensor Function
AIN1 VDO 10 Bar OIL PRESSURE (PAGE 508)
AIN2 VDO40-120°C COOLANT TEMP (PAGE 508)
AIN3 VDOLevel % FUEL LEVEL (PAGE 508)
To Next Page
