InteliLite4 AMF20 Global Guide
490
Related FW 1.3.0 Related applications AMF,MRS
Comm object 1258
Description
This output is active when controller is in MAN mode and the engine is stopped and it is possible to start it
i.e. no red alarm is activated or SD OVERRIDE (PAGE 460) is active (Output READY (PAGE 498) is active).
Manual Ready
6 back to Logical binary outputs alphabetically
Related FW 1.3.0 Related applications AMF,MRS
Comm object 34
Description
This output provides 1s pulse when:
MCB button is pressed on the controller front facia or
MCB button is pressed on any of external local/remote terminals or
MCB command is received via communication line or
the input MCB BUTTON is activated.
MCB Button Echo
6 back to Logical binary outputs alphabetically
Related FW 1.3.0 Related applications AMF,MRS
Comm object 2697
Description
LBO is active as long as it's button is pressed or it's LBI is active.
MCB Button State
6 back to Logical binary outputs alphabetically
Related FW 1.3.0 Related applications AMF,MRS
Comm object 45
Description
The output controls the mains circuit breaker. Its state represents the breaker position requested by the
controller. The breaker must react within 5 seconds to a close or open command, otherwise an alarm is
issued.
Note: InteliLite 4 controller can work even without breaker feedbacks, in this case do not configure the
feedback to binary inputs.
MCB Close/Open
