InteliLite4 AMF20 Global Guide
489
LBO: L
Related FW 1.3.0 Related applications AMF,MRS
Comm object 51
Description
Particular instances of the load shedding functionality
The load shedding outputs are activated (load is being shedd) in the order 1, 2, 3, 4, 5.
The load shedding outputs are deactivated (load is being reconnected) in the order 5, 4, 3, 2, 1.
The load disconnected by the LBO Nr.1 is the less essential load of these three possible loads instances.
Load Shedding Stage 1
6 back to Logical binary outputs alphabetically
Related FW 1.3.0 Related applications AMF,MRS
Comm object 52
Description
Particular instances of the load shedding functionality
The load shedding outputs are activated (load is being shedd) in the order 1, 2, 3, 4, 5.
The load shedding outputs are deactivated (load is being reconnected) in the order 5, 4, 3, 2, 1.
The load disconnected by the LBO Nr.1 is the less essential load of these three possible loads instances.
Load Shedding Stage 2
6 back to Logical binary outputs alphabetically
LBO: M
Related FW 1.3.0 Related applications AMF,MRS
Comm object 78
Description
This output is active while mains failure is not detected and mains voltage and frequency is within limits.
Mains Healthy is active when mains f and V are within the protection limits
Mains Healthy deactivates when there is active mains protection level 2
Mains Healthy cannot be activated when there is inactive not confirmed alarm Sd Emergency
Stop (page 559) in the alarmlist
Note: Mains Healthy cannot be activated when there is active ALI Mains Ph Rotation Opposite
(page 550) or ALI Mains Ph L1 Inverted (page 549), ALI Mains Ph L2 Inverted (page 549) or ALI
Mains Ph L3 Inverted (page 549).
Mains Healthy
6 back to Logical binary outputs alphabetically
