InteliLite4 AMF20 Global Guide
488
Image 8.45 Ignition 1
Image 8.46 Ignition 2
6 back to Logical binary outputs alphabetically
Related FW 1.3.0 Related applications AMF,MRS
Comm object 1257
Description
This output is on since start button is pressed till the unit is completely stopped (or the engine doesn’t start
or Sd or E-Stop is active)
Note: This function is the same as ECU POWER RELAY (PAGE 474). Ignition ON stays there from
historical reasons.
Ignition On
6 back to Logical binary outputs alphabetically
Related FW 1.3.0
Related
applications
AMF,MRS
Comm object 1222
Description
This output is activated when the engine proceeded through initialization phase. (Initialization phase is
restart or power up of the controller.)
Initialized
6 back to Logical binary outputs alphabetically
