InteliLite4 AMF20 Global Guide
157
ALTERNATE CONFIG 2 (PAGE 439) ALTERNATE CONFIG 3 (PAGE 439) Active configuration set
0 0 1
1 0 2
0 1 3
1 1 3
IMPORTANT: Gen-set can not switch to the alternative setpoints when running.
5.5.23 USB host
USB host is a function for programming the controller from the USB Flash Drive. In order to get the latest
firmware and archive to USB flash drive following steps have to be followed:
Download and install latest .psi package from www.comap-control.com
Use InteliConfig -> Tools -> USB Flash Export -> Export Manager
There must be 4 files generated or copied on USB flash drive.
Note: M.N.P.B stands for number 0 – 9.
The following functions are supported:
Firmware upload (Access level 3 is required)
Configuration upload (Access level 3 is required)
Firmware and configuration upload (Access level 3 is required)
Configuration download (Access level 0 is satisfactory)
IMPORTANT: Do not unplug USB Flash Drive during programming!
