InteliLite4 AMF20 Global Guide
450
Related FW 1.3.0 Related applications AMF,MRS
Comm object 63
Description
Use this input for indication whether the generator circuit breaker is open or closed.
Image 8.25 GCB Feedback 1
Image 8.26 GCB Feedback 2
Note: InteliLite 4 controller can work even without breaker feedbacks, in this case do not configure the
feedback to binary inputs.
GCB Feedback
6 back to Logical binary inputs alphabetically
Related FW 1.3.0 Related applications AMF,MRS
Comm object 219
Description
This binary input can be used to adjust home position of gen-set. In case that binary input is active,
setpoints Home Latitude (page 324) and Home Longitude (page 325) are adjusted automatically from
actual coordinates from GPS signal.
Note: Input has to be activated for at least 2 seconds.
Geo Home Position
6 back to Logical binary inputs alphabetically
