InteliLite4 AMF20 Global Guide
453
Related FW 1.3.0 Related applications AMF,MRS
Comm object 65
Description
Use this input for indication whether the mains circuit breaker is open or closed.
Image 8.27 MCB Feedback 1
Image 8.28 MCB Feedback 2
Note: InteliLite 4 controller can work even without breaker feedbacks, in this case do not configure the
feedback to binary inputs.
MCB Feedback
6 back to Logical binary inputs alphabetically
