InteliLite4 AMF20 Global Guide
314
Timer 3 Refresh Period
Setpoint group Scheduler Related FW 1.3.0
Range [units] [-]
Default value [-] Alternative config NO
Step [-]
Comm object 0 Related applications AMF,MRS
Config level Standard
Setpoint visibility Conditioned by the setpoint Timer 3 Function (page 308)
Description
Refresh period of Timer 3 Function (page 308). Meaning of this setpoint depends on type of repetition
adjusted in Timer 3 Repeated (page 311).
Daily
Range [units]: 1 .. 1000 [day]. This setpoint adjust that every X day the timer
will be activated.
Example: If you have daily repetition and you set this setpoint to 3, then
every second day from first occurrence of Timer 3 Function (page 308),
the Timer 3 Function (page 308) will be activated.
Weekly
Range [units]: 1 .. 60 [week]. This setpoint adjust that every X week the timer
will be activated.
Example: If you have weekly repetition and you set this setpoint to 3, then
every second week from first occurrence of Timer 3 Function (page 308),
the Timer 3 Function (page 308) will be activated in selected days
adjusted by Timer 3 Day (page 312).
Monthly
Range [units]: 1 .. 12 [month]. This setpoint adjust that every X month the timer
will be activated.
Example: If you have monthly repetition and you set this setpoint to 3, then
every second month from first occurrence of Timer 3 Function (page 308),
the Timer 3 Function (page 308) will be activated in selected day of month
adjusted by Timer 3 Repeat Day In Month (page 312) or in selected days
of week of month adjusted by Timer 3 Day (page 312) and Timer 3
Repeat Week In Month (page 313).
Short Period
Range [units]: [HH:MM]. This setpoint adjust that every X short period the timer
will be activated.
Example: If you have short period repetition and you set this setpoint to 3,
then every second minute from first occurrence of Timer 3 Function (page
308), the Timer 3 Function (page 308) will be activated.
6 back to List of setpoints
