InteliLite4 AMF20 Global Guide
390
Group: Engine
RPM
Value group Engine Related FW 1.3.0
Units RPM
Comm object 10123 Related applications AMF,MRS
Description
This value contains the current engine speed. The value is obtained from one of the following sources:
ECU, if an ECU is configured
Pickup input
Generator frequency
6 back to List of values
ECU Frequency Select
Value group Engine Related FW 1.3.0
Units -
Comm object 12926 Related applications AMF,MRS
Description
Shows selected frequency of ECU. The value is calculated from setpoint Nominal Frequency (page 215)
If is Nominal Frequency (page 215) in range from 45 Hz to 54 Hz, is considered as 50 Hz
application. The value is set to 0.
If is Nominal Frequency (page 215) in range from 55 Hz to 65 Hz, is considered as 60 Hz
application. The value is set to 1.
6 back to List of values
ECU AIN 1
Value group Engine Related FW 1.3.0
Units Depends on ECU value
Comm object 10153 Related applications AMF,MRS
Description
This is one of the inputs, which are defined by ECU. Order of values depends on type of ECU.
Note: Usually there are engine speed[RPM], fuel rate[L/h], coolant temperature[°C], intake
temperature[°C], oil pressure[bar], boost pressure[bar], load[%], oil temperature[°C] etc.
6 back to List of values
