InteliLite4 AMF20 Global Guide
520
Group: Other functions
PLC group Other functions
Related FW 1.3.0
Related applications AMF,MRS
Comm object
Inputs
Input Type Negation Range Function
Input Analog No -2147483647..2147483647
Value to be
"decomposed" to bits
Outputs
Output Type Negation Range Function
Output 1 Binary Yes 0/1
Bit 0,4,8,12,16,20,24,28 – according
to selected group of bits.
Output 2 Binary Yes 0/1
Bit 1,5,9,13,17,21,25,29 – according
to selected group of bits.
Output 3 Binary Yes 0/1
Bit 2,6,10,14,18,22,26,30 –
according to selected group of bits.
Output 4 Binary Yes 0/1
Bit 3,7,11,15,19,23,27,31 –
according to selected group of bits.
Description
The block converts the input analog value to binary form and provides selected bits as binary outputs.
Image 8.71 Configuration of Comp Time block
Note: Input 2 and Delay can be constants or values from the controller.
Decomposer
6 back to List of PLC blocks
