InteliLite4 AMF20 Global Guide
607
Number of channels 1
Current
Range: 0 to 20 mA ± 0.33 mA
Resolution 10 bit
Analog outputs
Number of channels 8
Input resistance 4700 Ω
Input range 0 to 36 V DC
Switching voltage level for open contact
indication
0 to 2 V DC
Max voltage level for close contact
indication
8 to 36 V DC
Binary inputs
Number of channels 8
Max current 500 mA
Max switching voltage 36 V DC
Number of channels 8
Voltage
Range 0-100 mV
Accuracy: 1.5 % ±.1 mV out of measured value
Current
Range: 0-20 mA
Accuracy: 2.5 % ± 0.5Ω out of measured value
Resistive
Range: 0-250 Ω
Accuracy: 1 % ±2Ω out of measured value
Binary outputs
Inteli AIN8TC
Inteli AIN8TC module is an extension module equipped with 8 analog inputs dedicated for thermocouple
sensors only.
The detection of communication speed is indicated by rapid flashing of status LED. Once the speed is
detected the module remains set for this speed even when the communication is lost. Renewal of
communication speed detection is done by resetting of the module.
