Nominal Power – writing
Table: Setpoints
Allowed MODBUS functions: 03, 04, 06, 16
Register(s) Com.Obj. Name Dimension Type Len Dec Min Max Group
03008 8276
Nominal
Power
kW Unsigned 2 0 1 5000
Basic
Settings
Request: (Numbers in Hex)
01 06 0B C0 00 64 8A 39
Controller address Modbus function
Register address
0BC0
hex
= 3008
dec
Data
0064
hex
= 100
dec
CRC
Response: (Numbers in Hex)
01 06 0B C0 00 00 8B D2
Controller address Modbus function
Register address
0BC0
hex
= 3008
dec
Allways zero CRC
Writen setpoint nominal power is 100 kW.
CRC calculation
The check field allows the receiver to check the validity of the message. The check field value is the Cyclical
Redundancy Check (CRC) based on the polynomial x
16
+x
15
+x
2
+1. CRC is counted from all message bytes
preceding the check field.
Online CRC calculator: http://www.lammertbies.nl/comm/info/crc-calculation.html Use CRC-16 (Modbus)
Write LSB first.
For writing nominal power 100 kW the CRC is calculated from this data: 01060BC00064
hex

ComAp InteliLite AMF25 Specifications

General

Inputs	8 binary inputs
Outputs	8 binary outputs
Power Supply	8-36 V DC
Communication	RS232, RS485
Operating Temperature	-20°C to +70°C
Supported Generators	Diesel, gas
Controller Type	Automatic Mains Failure Controller
Protection	IP65
