8.1.2 Values
What values are:
Values (or quantities) are analog or binary data objects, measured or computed by the controller, that are
intended for reading from the controller screen, PC, MODBUS, etc. Values are organized into groups according
to their meaning.
Invalid flag
If valid data is not available for a particular value, the invalid flag is set to it. This situation may be due to the
following:
The value is not being evaluated in the scope of the current application and configuration.
Sensor fail has been detected on an analog input.
The configured ECU or extension module does not provide the particular value.
The communication with the ECU or extension module is interrupted.
A value containing the invalid flag is displayed as “####” in InteliConfig and on the controller screen. If such a
value is read out via MODBUS, it will contain the data 32768 in the case of signed values and 65535 in the case
of unsigned values.
List of values groups
Group: Engine 478
Group: Generator 482
Group: Load 485
Group: Mains 490
Group: Controler I/O 492
Group: Statistics 494
Group: IL Info 499
Group: Log Bout 502
Group: CM-GPRS 504
Group: CM-4G-GPS 509
Group: CM-Ethernet 515
Group: Date/Time 518
Group: Plug-In I/O 518
Group: PLC 519
For full list of setpoints go to the chapter List of values (page 476).
