ComAp InteliLite AMF25 User Manual

InteliLite Global Guide
572
LBO: F
Related FW 1.9.0 Related applications AMF, MRS
Comm object 592
Description
This output provides 1s pulse when:
Fault Reset button is pressed on the controller front facia or
Fault Reset button is pressed on any of external local/remote terminals or
Fault Reset command is received via communication line or
the input FAULT RESET BUTTON is activated.
Fault Reset
6 back to Logical binary outputs alphabetically
Related FW 1.9.0 Related applications AMF, MRS
Comm object 1815
Description
The Frequency select output is opened when Nominal Frequency (Frequency Settings) is equal to 50Hz and
closed when Nominal Frequency (Frequency Settings) is equal to 60Hz.
Frequency Select
6 back to Logical binary outputs alphabetically
Related FW 1.9.0 Related applications AMF, MRS
Comm object 1253
Description
Output closes when the value of Fuel Level lies under the value of Fuel Pump On (page 217) setpoint and
opens when value of Fuel Pump Off (page 218) is reached.
This output also can be closed by binary input FUEL PUMP ON/OFF (PAGE 529). In this case the binary
output FUEL PUMP ON (PAGE 217) is closed until the binary input FUEL PUMP ON/OFF (PAGE 529) is active
or until the value of Fuel Level reaches 100%.
Note: Setpoints Fuel Pump On (page 217) and Fuel Pump Off (page 218) are invisible until
configuration of this LBO.
Fuel Pump
6 back to Logical binary outputs alphabetically
Related FW 1.9.0 Related applications AMF, MRS
Comm object 22
Description
This output controls the fuel solenoid valve. The Fuel Solenoid output has two different behaviors depending
on engine type – gas or diesel. This setting is done by Fuel Solenoid (page 189) setpoint in Engine Settings
group.
Fuel Solenoid

ComAp InteliLite AMF25 Specifications

General

Inputs	8 binary inputs
Outputs	8 binary outputs
Power Supply	8-36 V DC
Communication	RS232, RS485
Operating Temperature	-20°C to +70°C
Supported Generators	Diesel, gas
Controller Type	Automatic Mains Failure Controller
Protection	IP65
