InteliLite Global Guide
574
Related FW 1.9.0 Related applications AMF, MRS
Comm object 3
Description
Output closes when any warning alarm appears.
The output opens, if:
No warning alarm is active and
Fault reset button is pressed
AL Common Wrn
6 back to Logical binary outputs alphabetically
Related FW 1.9.0 Related applications AMF, MRS
Comm object 1295
Description
The output is closed when there is the Wrn Coolant Temperature Low (page 693) alarm from the
COOLANT TEMP (PAGE 667) in the alarmlist or isn’t confirmed.
AL CoolantTemp Low
6 Logical binary outputs alphabetically (page 568)
Related FW 1.9.0 Related applications AMF, MRS
Comm object 1421
Description
The output is closed when there is the shutdown or BOC alarm from the COOLANT TEMP (PAGE 667) in the
alarmlist or isn’t confirmed.
AL CoolantTemp Sd
6 Logical binary outputs alphabetically (page 568)
Related FW 1.9.0 Related applications AMF, MRS
Comm object 1420
Description
The output is closed when there is the warning alarm from the COOLANT TEMP (PAGE 667) in the alarmlist or
isn’t confirmed.
Note: Binary output is also active if protection type is set to HistRecOnl and threshold level for history
record is reach.
AL CoolantTemp Wrn
6 back to Logical binary outputs alphabetically
