InteliLite Global Guide
635
Image 8.207 Stop Solenoid 2
Note: If Additional running engine indications (page 132) went off during 5 s pause than Stop
Solenoid is not activated again otherwise stop solenoid is activated again.
6 Logical binary outputs alphabetically (page 568)
Related FW 1.9.0 Related applications AMF, MRS
Comm object 1249
Description
The binary output depends on measured generator active power. Power is compared with generator nominal
active power with use of hysteresis and with delay of switch 1 s.
When the measured active power is equal to or bigger than 5 % of Nominal Power (page 191) for 1 s then
the binary output is closed.
When the measured active power is equal to or lower than 3 % of Nominal Power (page 191) for 1 s then
the binary output is opened.
Supplying Load
6 back to Logical binary outputs alphabetically
Related FW 1.9.0 Related applications AMF, MRS
Comm object 1997
Description
This logical binary output is result of internal comparator which compares statistic values Running Hours
(page 497) and Pulse Counter 2 (page 496). Binary output is active when Running Hours (page 497) are
equal or higher than the Pulse Counter 2 (page 496).
Swap Start
6 back to Logical binary outputs alphabetically
