ComAp InteliLite AMF25 User Manual

InteliLite Global Guide
646
Group: Other functions
PLC group Other functions
Related FW 1.9.0
Related applications AMF, MRS
Comm object 9
Inputs
Input Type Negation Range Function
Input Binary No 0/1
A record with configured text is
recorded into the controller history
when the input is activated.
Outputs
No outputs.
Description
This block writes a record with defined text into the history when the input is activated.
Image 9.11 Configuration of Force Hist block
Note: Maximal number of characters for history message is 15.
Force History Record
6 back to List of PLC blocks
PLC group Other functions
Related FW 1.9.0
Related applications AMF, MRS
Comm object 10
Inputs
Input Type Negation Range Function
Lvl 1 Binary No 0/1
The input activates yellow level of the
configured protection if it is configured
Lvl 2 Binary No 0/1
The input activates red level of the
configured protection if a red level
protection is configured
Fls Binary No 0/1
The input activates sensor fail if a fls
protection is configured
Force Protection

ComAp InteliLite AMF25 Specifications

General

Inputs	8 binary inputs
Outputs	8 binary outputs
Power Supply	8-36 V DC
Communication	RS232, RS485
Operating Temperature	-20°C to +70°C
Supported Generators	Diesel, gas
Controller Type	Automatic Mains Failure Controller
Protection	IP65
