ComAp InteliLite AMF25 User Manual

InteliLite Global Guide
673
Shutdown
Alarm Type Shutdown
Alarmlist message Emergency Stop
Alarm evaluated All the time
Related applications AMF, MRS
Description
Alarm is activated when binary input EMERGENCY STOP (PAGE 528) is activated.
The gen-set shuts down in the moment the input is activated and starting is
blocked until the input is deactivated and fault reset is pressed.
Note: Use red emergency button placed on the switchboard door and connect
it to a binary input of the controller. Then configure the function Emergency
Stop to this binary input. It is recommended to use NC contact of the button.
Note: The MCB control is not affected by this alarm.
Emergency Stop
6 back to List of alarms level 2
Alarm Type Sd
Alarmlist message Sd + Name of analog input
Alarm evaluated All the time
Related applications AMF, MRS
Description
This alarm indicates that value the general analog protection is out of shutdown
protection limit.
Sd AIN Protec
6 back to List of alarms level 2
Alarm Type Shutdown
Alarmlist message Sd Battery Flat
Alarm evaluated During cranking
Related applications AMF, MRS
Description
This alarm will be issued if the controller was reset during cranking of the gen-set.
If this situation occurs, the controller supposes the starting battery is so exhausted
that its voltage drops so low when starter motor is energized that it causes
controller reset.
Sd Battery Flat
6 back to List of alarms level 2
Alarm Type Shutdown
Alarmlist message Sd + Name of binary input
Alarm evaluated All the time
Sd BIN Protection

ComAp InteliLite AMF25 Specifications

General

Inputs	8 binary inputs
Outputs	8 binary outputs
Power Supply	8-36 V DC
Communication	RS232, RS485
Operating Temperature	-20°C to +70°C
Supported Generators	Diesel, gas
Controller Type	Automatic Mains Failure Controller
Protection	IP65
