ComAp InteliLite AMF25 User Manual

InteliLite Global Guide
679
Related applications AMF, MRS
Description
This alarm evaluates the generator phase voltage in phases 3. The following
setpoints are related to it:
Generator Undervoltage BOC (page 231)
Generator <> Voltage Delay (page 232)
6 back to List of alarms level 2
Alarm Type Shutdown
Alarmlist message Sd Generator L3L1 > Voltage
Alarm evaluated Generator excited only
Related applications AMF, MRS
Description
This alarm evaluates the generator phase to phase voltage between phases 3 and
1. The following setpoints are related to it:
Generator Overvoltage Sd (page 230)
Generator <> Voltage Delay (page 232)
Sd Generator L3L1 > Voltage
6 back to List of alarms level 2
Alarm Type Shutdown
Alarmlist message Sd Generator L3L1 < Voltage
Alarm evaluated Generator excited only
Related applications AMF, MRS
Description
This alarm evaluates the generator phase to phase voltage between phases 3 and
1. The following setpoints are related to it:
Generator Undervoltage BOC (page 231)
Generator <> Voltage Delay (page 232)
Sd Generator L3L1 < Voltage
6 back to List of alarms level 2
Alarm Type Shutdown
Alarmlist message Sd Generator > Frequency
Alarm evaluated Generator excited only
Related applications AMF, MRS
Description
This alarm evaluates the generator frequency in the phase L1. The following
setpoints are related to it:
Generator Overfrequency BOC (page 233)
Generator <> Frequency Delay (page 234)
Sd Generator > Frequency
6 back to List of alarms level 2

ComAp InteliLite AMF25 Specifications

General

Inputs	8 binary inputs
Outputs	8 binary outputs
Power Supply	8-36 V DC
Communication	RS232, RS485
Operating Temperature	-20°C to +70°C
Supported Generators	Diesel, gas
Controller Type	Automatic Mains Failure Controller
Protection	IP65
