ComAp InteliLite AMF25 User Manual

InteliLite Global Guide
680
Alarm Type Shutdown
Alarmlist message Sd Generator < Frequency
Alarm evaluated Generator excited only
Related applications AMF, MRS
Description
This alarm evaluates the generator frequency in the phase L1. The following
setpoints are related to it:
Generator Underfrequency BOC (page 234)
Generator <> Frequency Delay (page 234)
Sd Generator < Frequency
6 back to List of alarms level 2
Alarm Type Shutdown
Alarmlist message Sd Generator Voltage Unbalance Ph-Ph
Alarm evaluated Generator excited only
Related applications AMF, MRS
Description
This alarm evaluates the unbalance of the phase to phase voltage, i.e. the
difference between highest and lowest phase to phase voltage at any given time.
The following setpoints are related to it:
Voltage Unbalance BOC (page 232) adjusts the maximum allowed
difference between the highest and lowest phase voltage at any given time.
Voltage Unbalance BOC Delay (page 233) adjusts the alarm delay.
Sd Generator Voltage Unbalance Ph-Ph
6 back to List of alarms level 2
Alarm Type Shutdown
Alarmlist message Sd Generator Voltage Unbalance Ph-N
Alarm evaluated Generator excited only
Related applications AMF, MRS
Description
This alarm evaluates the unbalance of the phase voltage, i.e. the difference
between highest and lowest phase voltage at any given time. The following
setpoints are related to it:
Voltage Unbalance BOC (page 232) adjusts the maximum allowed
difference between the highest and lowest phase voltage at any given time.
Voltage Unbalance BOC Delay (page 233) adjusts the alarm delay.
Sd Generator Voltage Unbalance Ph-N
6 back to List of alarms level 2
Alarm Type Shutdown
Alarmlist message Sd Oil Pressure
Alarm evaluated Gen-set is running
Sd Oil Pressure

ComAp InteliLite AMF25 Specifications

General

Inputs	8 binary inputs
Outputs	8 binary outputs
Power Supply	8-36 V DC
Communication	RS232, RS485
Operating Temperature	-20°C to +70°C
Supported Generators	Diesel, gas
Controller Type	Automatic Mains Failure Controller
Protection	IP65
