ComAp InteliLite AMF25 User Manual

InteliLite Global Guide
683
Alarm Type BOC
Alarmlist message BOC + Name of binary input
Alarm evaluated All the time
Related applications AMF, MRS
Description
Binary input also can be adjusted like alarm. In this case message in alarmlist
contains prefix - BOC and binary input name. This alarm occurs, when appropriate
binary input is active.
BOC BIN Protection
6 back to List of alarms level 2
Alarm Type BOC
Alarmlist message BOC Coolant Temperature
Alarm evaluated All the time
Related applications AMF, MRS
Description
This alarm indicates that the coolant temperature is higher than the temperature set
in Coolant Temperature Sd (page 210) setpoint.
BOC Coolant Temp
6 back to List of alarms level 2
Alarm Type BOC
Alarmlist message BOC Current Unbalance
Alarm evaluated All the time
Related applications AMF, MRS
Description
This alarm evaluates the unbalance of the phase currents, i.e. the difference
between highest and lowest phase current at any given time. The following
setpoints are related to it:
Current Unbalance BOC (page 230) adjusts the maximum allowed
difference between the highest and lowest phase current at any given time.
Current Unbalance BOC Delay (page 230) adjusts the alarm delay.
BOC Current Unbalance
6 back to List of alarms level 2
Alarm Type BOC
Alarmlist message BOC Fence 1 Alarm
Alarm evaluated All the time
Related applications AMF, MRS
Description
This alarm evaluates the GPSposition of gen-set. The following setpoint are
related to it:
Geo-Fencing (page 324)
Fence 1 Protection (page 325)
Fence Radius 1 (page 323)
BOC Fence 1 Alarm

ComAp InteliLite AMF25 Specifications

General

Inputs	8 binary inputs
Outputs	8 binary outputs
Power Supply	8-36 V DC
Communication	RS232, RS485
Operating Temperature	-20°C to +70°C
Supported Generators	Diesel, gas
Controller Type	Automatic Mains Failure Controller
Protection	IP65
