Synchronization
Synchronization process
It is possible to influence the behavior of the controller in MAN and AUTO mode and limit the process of
synchronization. Following setpoints have influence to synchronization process:
Mains Coupling (page 171)
Synchronization R To Mains (page 172)
Synchronization L To Mains (page 173)
Synchronization R To L (page 173)
Synchronization L To R (page 173)
Dead Bus Closing (page 174)
BTB Opening (page 174)
Note: When the controller starts to synchronize and the main measuring screen is displayed, it will be
automatically change to the synchroscope screen for the entire duration of synchronization. After
synchronization the synchroscope screen is automatically changed back to the main measuring screen. It is
also possible to change screens manually (arrows up and down) after displaying the synchroscope screen. In
this case there is no automatic return to the main measuring screen after synchronization is finished.
Synchronization via BTB in AUTO mode
BTB controller controls the synchronization process. Behavior of synchronization depends on power sources of
bus left and bus right.
Dead bus Gen-sets Mains Gen-sets + Mains
Dead bus
BTB Opening
(page 174)
Dead Bus Closing (page
174)
Dead Bus Closing (page
174)
Dead Bus Closing (page
174)
Gen-sets
Dead Bus Closing
(page 174)
Synchronization R To L
(page 173)
Synchronization L To R
(page 173)
Synchronization L To R
(page 173)
Synchronization L To
Mains (page 173)
Synchronization L To R
(page 173)
Synchronization L To
Mains (page 173)
Mains
Dead Bus Closing
(page 174)
Synchronization R To L
(page 173)
Synchronization R To
Mains (page 172)
Mains Coupling (page
171)
Mains Coupling (page
171)
Gen-sets
+ Mains
Dead Bus Closing
(page 174)
Synchronization R To L
(page 173)
Synchronization R To
Mains (page 172)
Mains Coupling (page
171)
Mains Coupling (page
171)
Note: Power sources in left column are on left side and power sources in top row are on right side.
Synchronization without Mains
In situation when on both sides are only gen-sets, setpoint Synchronization R To L (page 173) or Synchronization L
To R (page 173) has to be enabled.
