ComAp IS-NTC-BB

IGS-NT Installation Guide
132
Leroy Somer: R 250
AVRi+
AVRi-
18VAC
From
generator
OUT1
OCOM
iG-
AVRi
iG
-
AVRi
TRANS
230/400VAC
0VAC
AVRI COM
AVRI OUT
J2
AVRi trim to minimum
counter clockwise.
VoltRegChar = POSITIVE
AVRDCout bias = 50%
Mecc Alte Spa: U.V.R.6
AVRi+
AVRi-
18VAC
From
generator
OUT1
OCOM
iG-
AVRi
iG
-
AVRi
TRANS
230/400VAC
0VAC
AVRI COM
AVRI OUT
AVRi output is connected instead Remote voltage trimmer 100Kohm
(OUT1=top position wire and GND =second top position).
AVRi trim to maximum
clockwise.
Volt/PF ctrl:
AVR DCout bias = 75%
VoltRegChar = NEGATIVE
Hint:
VoltRegChar = POSITIVE
is achived with IG-AVRi
OUT2 and GND
connection.
Mecc Alte Spa: S.R.7/2
AVRi+
AVRi-
18VAC
From
generator
OUT1
GND
iG-
AVRi
iG
-
AVRi
TRANS
230/400VAC
0VAC
AVRI COM
AVRI OUT
5B
7
AVRi trim to maximum
clockwise.
Volt/PF ctrl:
AVR DCout bias = 75%
VoltRegChar = NEGATIVE
Mecc Alte DSR
AVRi+
AVRi-
from generator
iG-
AVRi
iG
-
AVRi
TRANS
230/ 400VAC
0 VAC
AVRI COM
AVRI OUT
10
OCOM
11
OUT1
