IGS-NT Installation Guide
65
7.8.2. Terminals, Inputs and Outputs
Function
Terminals
Note
Mains voltage
L1,L2,L3, (N)
3x120 / 277 Ph-N or 207 / 480 Ph-Ph VAC
(neutral not needed), max 350 / 600VAC*,
CAT III
Bus voltage
L1,L2,L3, (N)
3x120 / 277 Ph-N or 207 / 480 Ph-Ph VAC
(neutral not needed), max 350 / 600VAC,
CAT III
Mains current
L1k,L1l, L2k,L2l,
L3k,L3l
0 ÷ 5 Amps, max 10 A all time, 150 A for 2
sec
0 ÷ 1 Amp, max 2 Amps all time
Aux current
IAk,IAl
0 ÷ 5 Amps, max 10 A all time, 150 A for 2
sec
0 ÷ 1 Amp, max 2 Amps all time
Power supply
+ , -
8 ÷ 36 VDC
Inputs and outputs
Binary inputs
BI1 ÷ BI12
Activation to minus power supply.
Binary outputs
BO1 ÷ BO12
Load is connected to plus power supply.
Analog inputs
AI1 ÷ AI3
Ohms, mA, Volts sensors
Analog outputs
AOUT-, AOUT-COM
Configurable analog output, mA, V.
Communication interface
RS232 (1)
D SUB9 (male)
PC: InteliMonitor, GenConfig or
Modem, GSM modem or
ECU (e.g. Cummins ModBus) or InteliVision
8
RS485 (Display) **
A1,B1,COMR1
Up to 3 IS-Displays (Remote display), up to
3 InteliVision 8 displays (remote display) or
3 InteliVision 5.
RS485 (2) **
A2,B2,COMR2
Redirected RS232 (2) see Basic
settings: RS485(2)conv.
PC: InteliMonitor, GenConfig
or Modem, GSM modem or InteliVision 8
USB
Electrical isolated
2.0 slave
PC: InteliMonitor, GenConfig
CAN1
L1,H1,COMC1
Extension modules: IS-AIN, IS-BIN,IGS-
PTM, IGL-RA15, I-AOUT
CAN2
L2,H2,CONC2
Intercontroller (Load&VAR sharing, Power
management), monitoring (IG-IB, I-LB) and
up to 4 InteliVision 8
RJ45 (Ethernet)
Ethernet cable
Remote monitoring via Ethernet,
InteliMonitor, WebSupervisor and etc…
NOTE:
Light blue IM-NTC-BB only.
* IG-MTU or IG-MTU-2-1 can be used for three wire systems, systems with separated
Neutral or when galvanic separation between generator or mains voltage and controller is
required.
** When more devices connected to RS485 bias resistor jumpers should be closed only on
one of them.
