ComAp IS-NTC-BB Installation Guide

IGS-NT Installation Guide
29
165 (6,5”)
38 (1,5”) 40 (1,6”)
~ 75 (3,0”)
~ 35 (1,4”)
180 (7,1”)
185 (7,3”)
106 (4,2”)
44 (1,7”)
54 (2,1”)
~ 25 (1,0”)
120 (4,7”) 125 (4,9”)
Cutout
for Remote Annunciator
167 x 108 mm
(6,6 x 4,3)”

5.3.8. IGS-PTM
95 mm
(3,7´´)
43 mm
(1,7´´)
96 mm (3,8´´)
COMPENSATION
GND
POWER
8-36V DC
BINARY OUTPUTS
BINARY INPUTS
ANALOG INPUTS
AI4
BI8 BI7 BI6 BI5 BI4 BI3 BI2 BI1
0-20 mA
ANALOG OUT
BO8 BO1 BO2 BO3 BO4 BO5 BO6 BO7
CAN
Rx
Tx
CAN
L
H
COM
LB 4
AO- AO+
iGS-PTM
IGS-PTM unit can be mounted on DIN rail (35mm).

ComAp IS-NTC-BB Specifications

General

Brand	ComAp
Model	IS-NTC-BB
Category	Controller
Language	English
